MAE 3340 Instrumentation and Measurements
Spring 2016
Downloadable Course Notes:
Each lecture-note section listed below will span approximately 1-2 weeks
Posted notes are identical to notes presented in class
- Theoretical and Background Material Lectures on Monday and Friday Lectures
- Laboratory Lectures will Typically be Delivered on Second-Half of Monday Lecture Period for "Week of" Lab
Section 1: Basic Measurement Concepts and Definitions
Section 2: Introduction to Analog Measurement Concepts
- Homework 3: Multimeter Sensitivity Problem
- Due at Beginning of Lab Sessions Week 5, February 8-12 2016.
- HINT: GO BACK AND REVIEW SECTION 1,2 NOTES, Slides 46-51 "Uncertainty Analysis and Error Propagation"
- Carefully Go Thru Example 3.15, Pages 78-81 in Beckwith.
- Homework 3 Solution Set
Section 3: Assessing and Classifying Experimental Data
Section 4: Introduction to Wheatstone Bridge-Based Strain Measurements
Midterm Exam Information
- Midterm Exam, Wednesday March 2, 2016
- Alternate Exam
- MAE Conference Room: 2:30 - 5:00 PM, Wednesday March 2.
- By arrangement only -- please contact instructor by email before C.O.B. Friday Feb 26
-
https://connect.usu.edu/p9o38oltctu/
Open Lecture Notes, Graded Homeworks and Lab Reports
• Comprehensive Thru Section 5 of Lecture Notes and Lab 5
• 7-Problems, 100 Total Points
1. Oscilloscope Settings (10 pts)
2. Ohm’s Laws and Circuit Analysis (15 pts)
3. Circuit Uncertainty Analysis (15 pts)
4. Fourier Analysis (20 pts)
5. Signal Analysis and Heterodyning (10 points)
6. Using t-test to Compare Performance of Two Independent Samples (15 pts)
7. Calibration and Curve Fit Error Analysis (15 pts)
Section 5: Signal Conditioning Basics: Introduction to the Operational Amplifier
Section 6: Introduction to Heat Transfer, Thermometry, and Temperature Measurements
Section 7: Introduction to Systems Engineering
Laboratory Assignments:
Each laboratory assignment posted below will span approximately 1-week.
Students are expected to read all prepretory materials prior to lab sessions
- No Laboratory Sessions
- Week 1 January 11-15, 2016 (First Week of Class)
- Week 6 February 15-19 2016 (President's Day "Short Schedule" Week)
- Week 9 February 29 - March 4, 2016 (Midterm Exam Week)
- Spring Break, March 7-11, no Class
- Week 10, March 21-25, "Catch up" week for students ... "general amnesty" for assignments not turned in ... Due Week 11 @ Lab 7.
- Weeks 13-14 Team-Directed Lab Sessions, Preparation of Final Design Project
- Week 15 and Finals Week, Project Final Reprots and Presentations
Laboratory 1: Introduction to Dimensional Metrology
- This Laboratory exercise compares the resolutions and accuracies of several displacement measurement tools with calibrated gage-block standards traceable to the National Institute of Standards (NIST)
- Reference Materials (assigned as pre-lab reading material)
- Laboratory Performed During Week 2, January 18-22, 2016.
- Report Due @ Beginning of Lab Session Week 3, January 25-29, 2016.
- Appendix to Laboratory 1: Further Examples of Resolution Error
Laboratory 2: Introduction to the LabVIEW Programming Language
- This exercise is designed to acquaint you with the LabvVIEW® programming language, including basic programming and data acquisition.
- Laboratory Performed During Week 3, January 25-29, 2016.
- Report Due @ Beginning of Lab Sessions Week 4, February 1-5, 2016.
Laboratory 3: Introduction to the Digital Multimeter for DC Voltage, Resistance, and Current Measurements
- Laboratory Performed During Week 4, February 1-5, 2016.
- For all tables use a self-generated Excel (.xlsx) spreadsheet, insert copy into lab report
- Report Due @ Beginning of Lab Sessions Week 5,
February 8-12, 2016.
- Link to MyDAQ User's Guide
Laboratory 4: Further Uses of Basic Electronic Test Equipment
- This exercise is designed to acquaint students with the basic electronic tools used in mechanical instrumentation.
- Heterodyning and aliasiing concepts are also introduced.
- Lab Performed During Week 5, February 8-12, 2016.
- Report Due at Beginning of Lab Sessions Week 7, February 22-26, 2016.
- Laboratory may require two lab periods to complete
- Short week (presidents day) used to complete labs for those not finishing in week 1
- "Walk in" for lab completion during week 6 (Feb 16-19)
- Monday Class Schedule, Tuesday February 16 (no Tuesday labs)
Laboratory 5: Using the Wheatstone Bridge to Measure Unknown Resistances
- Students will build a Wheatstone bridge and use it to measure the resistance of a randomly selected group of resistors
- Nominal resistance and a standard deviation of 5% of the nominal value (according to the manufacturer).
- Students will use your test results to statistically investigate this claim.
- Lab Performed During Week 7, February 22-26, 2016.
- Report Due at Beginning of Week 9, March 14-18, 2016 (After Spring Break)
- Lab 5 Collected Spreadsheet Data
- (All member lab sections not sending their data spreadsheets to me will receive a zero! for the lab score)
Laboratory 6: Strain Measurements on a Soda Can
- Students will build a Wheatstone bridge and use it to measure the resistance of a randomly selected group of resistors
- Nominal resistance and a standard deviation of 5% of the nominal value (according to the manufacturer).
- Students will use your test results to statistically investigate this claim.
- Laboratory Performed During Week 9, March 14-18, 2016.
- Report Due @ Beginning of Lab Sessions of Week 11, March 28-April 2, 2016.
- Pre-Lab Preparation (Complete before start of lab):
- Download Vishay Strain Gauge Installation Manual from MAE 3340 Web Page, Read Sections 2 and 3.
- Download Vishay P-3500 User Manual from MAE 3340 Web Page, Read Entire Manual.
- Based on Data Given on Lab 6 Lecture Notes, Predict anticipated range of strain when soda can is opened.
- Calculate anticipated output voltage range from Vishay Box AO channel.
Laboratory 7: Introduction to Op-Amps and High Impedance Amplifier Circuits
- In this lab students will learn about operational amplifiers by building a multiple purpose circuit that has the capability of acting as a
voltage polarity inverter, a high-impedance voltage follower, a voltage amplifier, and a voltage divider. All in 1 circuit!
- Laboratory Performed During Week 11, March 28-April 2, 2016
- Report Due @ Beginning of Lab Sessions Week 12, April 4-8, 2016.
- Prelab Calculation Sheet (complete before start of lab)
Laboratory 8: Using Thermocouples for Temperature and Heat Transfer Measurements
-
This lab will have two parts. In part (1) you will build an amplifier circuit for the TC output, and then calibrate both unamplified and amplified type "J" thermocouple outputs against reference temperature measurements. These calibrations allow absolute temperatures to be derived from the TC outputs. In part (2) will use the calibrated thermocouples to indirectly measure the convective heat transfer to a penny immersed in a beaker of hot water. This lab will allow students to understand the difference between temperature and heat.
Lab may span 2 weeks.
- Laboratory Performed During Week
- Report Due @ Beginning of Lab Sessions
- Each MAE 3340 lab section will design, build, integrate and test prototype oximeter d
esigns based on 1) photo-resistive, and 2) photo-generation technology.
- Each team will use the designs to evaluate team member resting pulse-rate and pulse-rate following vigorous activity (one round-trip up 4 flights of stairs in the ENGR building).
- Project team will use appropriate statistical analysis methods to make projections for the USU Engineering student body with regard to the resting heart rate and heart rate following vigorous activity (maximum heart rate).
- These projections will be compared to the USA population at large.
- Each laboratory section will work together as an integrated product team (IPT) with the entire team contributing to the development and testing of the final product.
Final Presentation Schedule
Each Presentation MUST contain the following elements.
- 1. Title Slide with Team Section, TA Name, Normal Meeting Time, and Team Name.
2. Organizational Chart Showing Team Members and Duty Assignments.
3. Background Theory and Concept of Operations for Each Device.
4. Functional Block Diagram of Each Device.
5. Software Description.
6. Example Time History Traces for Each Device.
- 7. Statistical Analysis of Results.
8. Lessons learned.
9. Conclusion
Please arrive on time as this will be a very full schedule. Will the systems engineer from
each of the listed sections below please send me
Panel ... the schedule for
..... 11:30-11:35 Introduction and Ground Rules
1) Section 506 -- 11:35-11:47
2) Section 508 -- 11:48-12:00
3) Section 510 -- 12:01-12:13
4) Section 512 -- 12:14-12:26
5) Section 514 -- 12:27-12:41
......
__________________________________________
... the schedule for
..... 09:30-09:35 Introduction and Ground Rules
1) Section 501 -- 09:35- 09:47
2) Section 502 -- 09:48-10:00
3) Section 503 -- 10:01-10:13
4) Section 504 -- 10:14-10:26
break ... (5 minutes)
5) Section 505 -- 10:31-10:43
6) Section 507 -- 10:44-10:56
7) Section 509 -- 10:57-11:09
8) Section 513 -- 11:10-11:22
...... 11:22 Summary & Follow up
__________________________________________
2015 Final Presentations and Briefings
